Description

The mixer features Pioneer’s Sound Color, Beat, and Frequency effects, and its horizontal X-Pad touchpad lets DJs manipulate and apply effects in real time. There are four inputs for turntables and four line-level inputs for digital decks. Additional features include: Pro DJ Link, four S/PDIF digital input connections, and one S/PDIF digital output connection. Connect two computers via the two top-mounted USB connections (USB-B and USB-C). Additionally, a Bluetooth input is available on every channel, allowing you to stream tracks from your favorite portable device while using all the mixer’s features and effects. The Multi I/O section has an independent channel selector to allow the use of external effects separately from Beat FX, giving the DJM-A9 true send capabilities.

Specifications:

Inputs:
DIGITAL X 4 (coaxial)
LINE x 4 (RCA)
PHONO x 4 (RCA)
MIC x 2 (XLR & 1/4″ TRS jack x 1, 1/4″ TRS jack x 1)

Outputs:
MASTER X 2 (XLR X 1, RCA X 1)
BOOTH X 1 (1/4″ TRS jack)
REC x 1 (RCA)
DIGITAL MASTER x 1 (coaxial)
PHONES x 4 (1/4″ stereo jack x 2, 3.5-mm stereo mini jack x 2)

USB:
USB Type-A x 1
USB Type-B / USB Type-C x 2

Others:
SEND (1/4″ TS jack) x 1
RETURN (1/4″ TS jack) x 1
LAN terminal (100BASE-TX) x 1

Frequency Response:
20 Hz – 40 kHz (LINE)

S/N Ratio:
114 dB (USB, Digital IN)
88 dB (PHONO)
105 dB (LINE)
79 dB (MIC 1, MIC 2)

Total Harmonic Distortion:
0.005% (LINE-MASTER1)

Power Consumption:
46 W

Maximum Dimensions (W x D x H):
407.4 × 458.3 x 107.9 mm (with the wireless antenna 140.7 mm) 16.4″ x 18.4″ x 4.25″ (with the wireless antenna 5.54″)

Weight:
10.2 kg / 22.5 lb

Accessories:
Power cord
Quick Start Guide
Precautions for Use

Compatible Software:
rekordbox
Serato DJ Pro
Showkontrol
PRO DJ LINK Bridge

Features:

• All-in-one DJ system with everything you need to start spinning: two CDJ-3000 players and a DJM-A9 mixer
• High-resolution audio playback and recording
• Pro-grade features like Beat Sync, Key Sync, and Slip Loop
• Built-in touchscreen display for easy navigation
• Robust construction for heavy-duty use

If you’re looking for the best possible DJ system, the Pioneer DJM-A9 is the perfect choice for you.
